Indications
| Model | Primary Urology Indications | Additional Applications |
| 40W | - Urinary stones (bladder, ureter, kidney lithotripsy) - Small BPH ablation/vaporization - Urethrotomy/strictures |
- Minor ENT (sialolithiasis) - Gallbladder stones - Polypus removal - PLDD (percutaneous laser disc decompression) |
| 90W | - Urinary lithotripsy - Prostatectomy (BPH HoLEP) - Urethral strictures |
- Vascular/gastro polyps - Early digestive cancer |
| 120W | - Large stones lithotripsy - HoLEP (moderate-large BPH) - Bladder tumor ablation |
- ENT (turbinectomy, laryngeal) - Gynecology (endometrial ablation, polyps) - Orthopedics/arthroscopy (spine discectomy, osteophytes) - Gastroenterology (polyp removal) - Vascular/thoracic (coagulation) - Dermatology/plastic (soft tissue) - Neurology/pulmonology |
| 160W | - High-volume HoLEP (large prostates >80g) - Complex stone dusting/enucleation |
- ENT, gynecology, gastroenterology, orthopedics (arthroscopy/foraminoplasty) - Vascular/thoracic, plastic surgery, oral, hemorrhoids |
Technical Specifications
| Parameter | 40W (HZ-40) | 90W (HZ-90) | 120W (HP-120) | 160W (HP-160+) |
| Max Power | 40W | 90W | 120W | 160W |
| Pulse Energy | 0.1-6.0J / 0.5-4.0J | 0.5-4.5J | 0.1-7.0J | 0.1-8.0J |
| Pulse Frequency | 30Hz / 5-20Hz | 5-40Hz | 2-100Hz | 2-120Hz |
| Wavelength | 2100nm Ho:YAG | 2100nm Ho:YAG | 2100nm Ho:YAG | 2100nm Ho:YAG |
| Aiming Beam | Green 532nm <1mW | Green 532nm <1mW , can be fine tuned | Green 532nm <1mW, can be fine tuned | Green 532nm <1mW, can be fine tuned |
| Fiber | 200-1000µm reusable | 200-1000µm reusable | 200-1000µm reusable | 200-1000µm reusable |
| Cooling | Internal | Internal | Internal | Internal |
| User Interface | Touchscreen, user-friendly | Touchscreen, adjustable parameters | Touchscreen, large display | Touchscreen, large size touchscreen |
| Special Features | Energy feedback, closed loop control | High absorption, reduced penetration | Cannon Double Pulse Technology | Advanced dual pulse technology |
| Noise Level | Low noise level | About half noise of conventional lasers | Low noise level | Low noise level |
| Power Supply | AC 220V-240V, 50/60 Hz | AC 220V-240V, 50/60 Hz | AC 220V-240V, 50/60 Hz | AC 220V-240V, 50/60 Hz |
| Pulse Duration | 50-1500μs (short/medium/long; up to 2000μs) / 300 - 600μs | 300 - 600μs | 50-2500μs (multi-modes, Cannon tech) | 50-2500μs+ (Cannon Double Pulse, expert modes) |
