ABM Brand
Suction Machine 7E- A”
The 7E-A Suction Machine is designed for high negative pressure and low flow operation, making it ideal for effective airway suction in clinical settings. It operates on an AC 220V power supply with a frequency of 50 Hz and consumes 250 VA of input power. The device provides a limit negative pressure of ≥0.075 MPa, with an adjustable range starting from 0.02 MPa. It delivers a suction rate of ≥15L/min and comes equipped with a 1000 mL liquid storage bottle, ensuring efficient and continuous operation.
Features
- Designed for high negative pressure and low flow operation
- Operates on AC 220V power supply
- Frequency of operation is 50 Hz
- Consumes 250 VA input power
- Provides limit negative pressure of ≥0.075 MPa
- Adjustable negative pressure range from 0.02 MPa to limit pressure
- Offers suction rate of ≥15 L/min.
- Equipped with one 1000 mL liquid storage bottle
- Operates with noise level ≤65 dB(A)
- Not suitable for use in inflammable or explosive environments
Technical Specification
| Power Supply | AC 220V |
| Frequency | 50 Hz |
| Input Power | 250 VA |
| Limit negative pressure | ≥0.075 MPa |
| Negative pressure regulating range | 0.02 MPa~ limit negative pressure |
| Suction Rate | ≥15 L/min |
| Liquid storage bottle | 1000 mL/pc, 1 pc |
| Noise | ≤65 dB (A) |
| Weight | 3.6 KG |
